Part Number:SWLD-1550-40-PM
Product Description: The SWLD High Power series laser diodes cover customer selection of large wavelengths from 1527.61nm to 1610.07nm which are fabricated in a hermetically sealed 14-pin butterfly package. The laser diodes contains thermoelectric cooler (TEC), thermistor, monitor photodiode, optical isolator to secure high quality laser performance. We also have full customer selection of output powers, package types and output fibers of SM fibers, PM fibers and other special fibers. Our laser products are Telcordia GR-468 qualified, and in compliance with RoHS directives.
Applications:
█ LAN, WAN and metro networks
█ C/DWDM systems
█ Fiberoptic sensors
█ Laser sources
█ CATV systems
Features:
█ High output power(40~100mW)
█ High-performance, multiquantum well (MQW) distributed-feedback (DFB) laser
█ Industry-standard, 14-pin butterfly package
█ Built-in TEC and optical isolator
█ ITU wavelengths available from 1527 nm —1610nm
█ Customer selection of wavelengths
Reliability: Telcordia GR-468. RoHS
